M.S. Bars (Mild Steel Bars) are solid, long, and rectangular metal rods made from mild steel, a low-carbon steel that offers good weldability, machinability, and ductility. These bars are used in a wide range of construction and industrial applications due to their strength, flexibility, and ease of fabrication. M.S. Bars are typically used in reinforcement for concrete structures, such as in buildings, bridges, and roads, as well as in manufacturing machinery and tools. They come in various shapes, including round, square, and rectangular, and in different grades depending on the strength and hardness required for specific applications. These bars are highly versatile, cost-effective, and commonly used in both construction and general engineering projects.
| Size (mm) | Rounds (kg/m) | Sqrs. (kg/m) | Hex. (kg/m) | Oct. (kg/m) |
|---|---|---|---|---|
| 8 | 0.39 | 0.50 | 0.43 | 0.42 |
| 9 | 0.50 | 0.64 | 0.55 | 0.53 |
| 10 | 0.62 | 0.78 | 0.68 | 0.65 |
| 11 | 0.75 | 0.95 | 0.82 | 0.79 |
| 12 | 0.89 | 1.13 | 0.98 | 0.94 |
| 13 | 1.04 | 1.33 | 1.15 | 1.10 |
| 14 | 1.21 | 1.54 | 1.33 | 1.27 |
| 16 | 1.58 | 2.01 | 1.74 | 1.66 |
| 18 | 2.00 | 2.54 | 2.20 | 2.11 |
| 20 | 2.47 | 3.14 | 2.72 | 2.60 |
| 22 | 2.98 | 3.80 | 3.29 | 3.15 |
| 25 | 3.85 | 4.91 | 4.85 | 4.06 |
| 28 | 4.83 | 6.15 | 5.13 | 5.10 |
| 30 | 5.55 | 7.06 | 6.12 | 5.85 |
| 32 | 6.31 | 8.04 | 6.96 | 6.66 |
| 36 | 7.99 | 10.17 | 8.81 | 8.43 |
| 38 | 8.90 | 11.34 | 9.69 | 9.39 |
| 40 | 9.86 | 12.56 | 10.40 | 10.40 |
| 45 | 12.29 | 15.90 | 13.77 | 13.17 |
| 50 | 15.41 | 19.62 | 17.01 | 16.26 |
| 60 | 22.18 | 28.26 | ||
| 71 | 31.08 | 39.57 | ||
| 75 | 34.66 | 44.15 | ||
| 80 | 39.46 | 50.24 | ||
| 90 | 49.94 | 63.58 | ||
| 100 | 61.66 | 78.50 |
